| 最大可夾工件外徑 Maximum diameter grab items |
160 mm |
| 兩頂尖距離 Distance between centers |
750 mm |
| 床身上最大回轉直徑 Swing over bed |
290 mm |
| 橫拖板上最大回轉直徑 Swing over cross slide |
165 mm |
| 主軸錐度 Taper of spindle bore |
MT5 |
| 主軸孔徑 Spindle bore |
38 mm |
| 調速類型 Step of spindle speeds |
無段變速 Variable |
| 主軸轉速範圍 Range of spindle speeds |
50-2000 rpm ±10% |
| 英制螺紋範圍 Range of inch threads |
8 – 56T.P.I |
| 公制螺紋範圍 Range of metric theads |
0.2-3.5mm |
| 中拖板橫向最大行程 Cross slide travel |
75 mm |
| 尾座套筒最大行程 Tailstock quil travel |
80 mm |
| 尾座套筒錐度 Taper of tailstock quill |
MT3 |
| 主電機 Motor |
1500W(單相電 220v) |
| 外形尺寸 Overall dimension |
1400x700x680 mm |
| 淨重 Net weight |
210 kg |
